LCD Screen 10 Zones Waterproof Walk Through Metal Detector for Security Checking LCD Screen 10 Zones Waterproof Walk Through Metal Detector  for Security Checking

JKDC-800C is a kind of high precision walk through metal detector, adopt international advanced digital detection technology, specifically detect metal and alloy items carried by human body. Overall design with fireproof, waterproof, shockproof, widening type design appearance, high safety, strong applicability, high sensitivity, wide detection range and good anti-interference performance, sound and light alarm at the same time can intelligent service 24 hours a day.

Quantity:
Share this:
Highlights

  • 6.0" Large screen LCD, user-friendly, simple and easy Chinese & English operation interface.

  • Optional 10 detection regions has high brightness LED indicator to position metals more accurately.

  • More than one doors can work together, max 20 sets doors in a group. Digital control over the computer.

  • High, low, mute alarm mode can be adjusted in different occasions according to requirements.

  • The sensitivity of each detection zone can be adjustable  independently between 0-99.

  • The combinations of digital and analog technology reduce the false positives, and improve the door stability.

  • With remote control, easy operation.

  • With modular design, easy demolition and installation


Specifications


Product Name10 Zones Walk Through Metal Detector

Model Number

 JKDC-800C

Alarm way

Audio Alert,and LED Location lamp work at same time

Display ways

Large Screen of LCD display

Tunnel Size 200(L)*68(W)*56(H)cm

Dimension

222(L)*80(W)*67(H)cm

Sensitivity0-99 adjustable
BoardThe mainbody with Waterproof function

Power

220VAC,50/60HZ

Power wastage

35W


Package



Package Size
Main Body230*72*25cm(2 piece /carton)
Host Machine78*47*28cm(1 piece/carton)
Net Weight51.5kg/set
Gross Weight71kg/set


×
